Porting vsftpd to ARM: Cross-Compile and Deployment Guide

Table of Contents

📖 Overview
#

This guide walks through how to cross-compile and deploy vsftpd (Very Secure FTP Daemon) on an ARM-based development board.

It covers:

Toolchain configuration
Compilation process
Deployment and setup
Service management and testing

🛠️ Environment Setup
#

Before starting, ensure the following environment is ready:

SDK: Fudan Micro (FM)
Build System: Buildroot 2018.02.3
Source Package: vsftpd-3.0.2.tar.gz

📦 Source Preparation
#

Create a workspace and extract the source code:

mkdir ~/vsftpd
cp vsftpd-3.0.2.tar.gz ~/vsftpd
cd ~/vsftpd
tar xzf vsftpd-3.0.2.tar.gz
cd vsftpd-3.0.2/

This prepares the source tree for cross-compilation.

⚙️ Toolchain Configuration
#

Edit the Makefile to use the correct ARM cross-compiler.

Locate and update the CC variable:

# Set your cross-compiler
CC = arm-linux-gnueabihf-gcc

Make sure:

The toolchain is installed
The compiler is available in your PATH

🧪 Compilation
#

Build the vsftpd binary using:

make

Expected output:

vsftpd → executable binary
vsftpd.conf → default configuration file

If compilation fails:

Verify toolchain path
Check missing dependencies
Ensure Buildroot environment is properly configured

🚀 Deployment to ARM Board
#

Transfer the compiled files to the target system:

Copy vsftpd → /usr/sbin/
Copy vsftpd.conf → /etc/

Set execution permissions:

chmod +x /usr/sbin/vsftpd

👤 User and Configuration Setup
#

Create FTP User
#

adduser ftp

Set a password when prompted.

Configure vsftpd
#

Edit /etc/vsftpd.conf:

anonymous_enable=YES
local_enable=YES
write_enable=YES
local_umask=022
listen=YES
ftp_username=ftp
secure_chroot_dir=/mnt/

Key Options Explained
#

anonymous_enable: Enables anonymous login
local_enable: Allows local users
write_enable: Enables uploads/deletions
secure_chroot_dir: Defines sandbox directory

▶️ Running the Service
#

Manual Start
#

/usr/sbin/vsftpd &

Auto-Start Configuration
#

Create init script:

/etc/init.d/S70vsftpd

Script content:

#! /bin/sh
set -e
DESC="vsftpd"
NAME=vsftpd
DAEMON=/usr/sbin/$NAME

case "$1" in
  start)
    printf "Starting $DESC: "
    start-stop-daemon -S -b -x $NAME
    echo "OK"
    ;;
  stop)
    printf "Stopping $DESC: "
    start-stop-daemon -K -x $NAME
    echo "OK"
    ;;
  restart|force-reload)
    $0 stop
    sleep 1
    $0 start
    ;;
  *)
    echo "Usage: $0 {start|stop|restart|force-reload}" >&2
    exit 1
    ;;
esac
exit 0

Make it executable:

chmod +x /etc/init.d/S70vsftpd

Control the service:

/etc/init.d/S70vsftpd restart

🌐 Client Testing
#

Test FTP connectivity from a PC:

ftp 192.168.31.45

Example session:

220 Welcome to FTP service.
User: ftp
Password: ******
230 Login successful.

ftp> ls
ftp> get file.txt
ftp> put upload.txt
ftp> quit

⚠️ Common Issues
#

Permission denied → Check file permissions and user rights
Connection refused → Ensure vsftpd is running and port is open
Login failure → Verify configuration and user credentials
Chroot errors → Ensure secure_chroot_dir exists and is accessible

🧾 Summary
#

Cross-compile vsftpd using ARM toolchain
Deploy binary and configuration to target system
Configure users and FTP settings
Enable manual or automatic service startup
Validate functionality via FTP client

This setup transforms an ARM development board into a lightweight and reliable FTP server, suitable for embedded systems and file transfer workflows.
