MCU Startup Explained: From Reset Vector to main()

Understanding how a Microcontroller Unit (MCU) starts execution is fundamental to embedded systems development. From the moment power is applied, a tightly defined sequence of hardware and software interactions determines how your program begins.

Whether working with a Cortex-M microcontroller or a higher-end Cortex-A processor, the startup process follows a structured and predictable flow.


🧭 Where the CPU Fetches Its First Instruction
#

At power-on or reset, the CPU does not “search” for code—it is hardwired to access a predefined memory location, traditionally address 0x00000000.

Cortex-M Startup Behavior
#

Modern ARM Cortex-M processors perform an automatic vector fetch:

  • Address 0x00000000 → Initial Stack Pointer (MSP)
  • Address 0x00000004 → Reset Handler address

These values are loaded into:

  • MSP (Main Stack Pointer)
  • PC (Program Counter)

Execution then jumps directly to the Reset_Handler, marking the true start of firmware execution.

Legacy Behavior (ARM7TDMI)
#

Older architectures like ARM7TDMI behave differently:

  • Execution begins directly at 0x00000000
  • Developers must place a branch instruction at that address

This makes Cortex-M startup more structured and less error-prone.


🧠 What Lives at Address 0x00000000?
#

The contents of address 0x00000000 are not fixed—they depend on the MCU’s boot configuration.

Common Memory Mapping Options
#

  • User Flash Memory

    • Standard production mode
    • Contains application firmware and vector table
  • System Memory (BootROM)

    • Manufacturer-provided bootloader
    • Used for firmware updates via UART, USB, etc.
  • Embedded SRAM

    • Used during debugging or fast execution scenarios

Boot Selection Mechanism
#

  • Controlled via BOOT pins, fuses, or configuration bits
  • Determines which memory region is mapped (aliased) to 0x00000000

Cortex-A Contrast
#

High-performance Cortex-A systems typically:

  • Start execution from internal BootROM
  • Initialize external memory controllers (DDR, QSPI, etc.)
  • Load application code into RAM before execution

This adds an additional boot stage compared to Cortex-M systems.


🧰 Linker Script: Defining the Vector Table
#

The placement of the vector table is controlled by the linker script, not by the compiler alone.

Key Concept
#

  • A dedicated section (e.g., .isr_vector) is defined
  • The linker ensures it is placed at the start of Flash memory

Example (GCC Linker Snippet)
#

KEEP(*(.isr_vector)) /* Ensure vector table is retained and placed correctly */

Startup File Role
#

In the startup assembly file (e.g., startup_xxx.s):

  • The vector table is explicitly defined
  • The first entry sets the initial stack pointer
  • The second entry points to Reset_Handler

This guarantees correct initialization during the hardware vector fetch.


🔄 Flexible Startup: Beyond Address 0x00000000
#

Modern MCUs provide more flexibility than earlier designs.

Vector Table Offset Register (VTOR)
#

High-end Cortex-M devices (e.g., Cortex-M7) include:

  • VTOR (Vector Table Offset Register)
  • Allows relocating the vector table to different memory regions

Benefits
#

  • Support for bootloaders
  • Dual-bank firmware updates
  • Running applications from external memory

Configuration Methods
#

  • Option bytes / configuration fuses
  • Software-controlled relocation via VTOR

This removes the strict dependency on address 0x00000000.


🔁 Complete Startup Flow
#

The MCU startup process can be summarized as follows:

  1. Hardware Reset

    • Power stabilizes
    • BOOT configuration is sampled
  2. Memory Mapping

    • Selected memory region is mapped to 0x00000000
  3. Vector Fetch

    • Initial SP and PC are loaded from the vector table
  4. Reset Handler Execution

    • Initializes system clocks (SystemInit)
    • Sets up memory (data/BSS sections)
  5. Application Entry

    • Control is transferred to main()

🧠 Final Take: Deterministic and Configurable
#

MCU startup may seem automatic, but it is the result of precise coordination between hardware design, linker configuration, and startup code.

  • Cortex-M systems emphasize deterministic startup via vector tables
  • Modern MCUs introduce flexibility through VTOR and boot configuration
  • Understanding this flow is essential for debugging, bootloader design, and system bring-up

Mastering MCU startup gives you full control over how your system powers on, initializes, and begins execution—a foundational skill in embedded development.
